40FT BSL 2 LAB

Overview:

BSL-2 laboratories are used to study moderate-risk infectious agents or toxins that pose a moderate danger if accidentally inhaled, swallowed, or exposed to the skin. Design requirements for BSL-2 laboratories include hand washing sinks, eye washing stations, and doors that close and lock automatically.



Design requirements for BSL-2 laboratories include hand washing sinks, eye washing stations in case of accidents, and doors that close automatically and lock. BSL-2 labs must also have access to equipment that can decontaminate laboratory waste, including an incinerator, an autoclave, and/or another method, depending on the biological risk assessment.

The GLSI 40FT BSL2 Lab is available in either static or trailer based options with expanding side pods on each model. The expanding side pod provides an increase in the width of the internal space providing a greater work area for users.

All our BSL 2 labs are designed through a consultation and design process which focuses on 3 aspects. Contact our team of complete a quote design form here.

  • Laboratory Features

  • Laboratory Furniture

  • Laboratory Equipment

BSL2 40FT Options

Code

Model

Width

Length

Height

m2 Space

Design Your Lab

GL8000-S40BSL2

Static 40FT BSL2

2438 mm

12190 mm

2896mm

30 m2

GL8000-S40BSL2P

Static 40FT BSL2 with Expanding Pod

5738 mm

12190 mm

2896mm

46.5 m2

GL8000-T40BSL2

Trailer 40FT BSL2

2438 mm

12190 mm

2896mm

30 m2

Trailer 40FT BSL2 with Expanding Pod

GL8000-T40BSL2P

12190 mm

5738 mm

2896mm

46.5 m2

BSL2 40FT LAB

Technical Specification

    Certification & Inspection

  • CSC Certified ISO 6346 compliant 40ft Standard Maritime Shipping Container

  • Independently inspected and accredited to CSC by an accredited external organisation

      Material

  • Heavy duty metallic body and external surfaces

  • Made of steel

  • Seamless welding

  • ISO reinforced corners and joints and floor supports x 8

  • External heavy duty expoxy paint



       External Side Walls & Roof

  • 50 mm XPS isolation material (total 62mm panel)

  • Double side 4mm MDF (Medium Density Fibreboard)

  • Double side 2 mm fiberglass sheet

  • Anti-bacterial, anti-static and UV (Ultraviolet stabiliser) panels

       3-room laboratory facility

  • 1 x laboratory room, airtight with access from the airlock filter room and with 1 x emergency exit, surface ≥ 16 m2

  • 1 x filter ante-room, airtight, between the entry room and the laboratory, doors preventing simultaneous opening surface ≥ 3 m2

  • 1 x entry room/specimen reception room, with 1 x external door and 1 x door to the filter ante-room preventing simultaneous opening, surface ≥ 3 m2

  • 1 x external technical room with external access, for installation and management of the technical systems

      Technical room

  • Separate to main laboratory and located at the container door ends with a steel bulkhead partition

  • Completely sealed from the main laboratory

  • Contains generator, water and waste tanks, electrical distribution board, HVAC system, back up batteries (if required), air compressor system and vacuum system

       Exterior

  • Three times coated corrosion protected

  • Steel structures sand blasted and shop primary coated

  • Resistant to to atmospheric elements and sunlight

Features

  • Anti-bacterial, anti-static and UV (ultraviolet stabilizer) panels

  • Technical and storage cabinets on trailer chassis laboratories for additional storage.

  • Expanding side pod increasing internal space to almost double.

  • All floor surfaces will be cover 2 mm anti-bacterial, Anti-static, anti-slip safe, washable hospital vinyl floor.

  • 600 mm x 1200 mm sun glass, high isolated. Tempered glass (black colour).

  • HVAC systems providing heat/cooling and negative and positive air pressure where needed.

  • 7 cm oval skirting all around the inside floor corners (anti-bacterial surface).

  • Custom laboratory grade furniture made to measure. Includes Steel construction, underwork cabinet, working table. High quality MDF material.

  • All utilities housed in a separate technical room for isolation of electrics, water and power supply.
